Lightweight Beam Structures Using Unidirectional Carbon Fiber Fabric
— A System‑Level “Gram‑Scale Weight, Ton‑Scale Stiffness” Solution for B2B Applications
1. Market Pain Points
- Aluminum beams have reached a weight‑reduction limit—becoming too thin compromises stability.
- Steel beams are overly heavy, negatively impacting cycle times and energy consumption.
- Conventional fabric layups waste fiber and fail to deliver adequate specific stiffness.
Unidirectional (UD) Carbon Fiber Fabric features 100 % 0° fiber orientation, boosting specific stiffness by 4–7× and specific strength by 6–10×. It is the ultimate lightweight core material for beam structures.
2. Product Specifications at a Glance (Stock & Customizable)
| Grade | Areal Weight (g/m²) | Fiber | Width (mm) | Resin System | Modulus (GPa) | Typical Applications |
|---|---|---|---|---|---|---|
| UD‑150 | 150 | T700‑12K | 300 / 600 / 1270 | Epoxy, 120 °C cure | 230 | Robotic arm beams |
| UD‑300 | 300 | T800‑12K | 300 / 1270 | Epoxy RTM | 294 | Automotive longitudinal beams |
| UD‑600 | 600 | M40J‑6K | 300 / 600 | High‑modulus epoxy | 377 | Precision optical platforms |
3. One‑Stop Beam Design Workflow (T+7 Days Delivery)
- Input Requirements
- Maximum bending moment M (kN·m)
- Allowable deflection δ (mm)
- Beam length L (m)
- Online Calculator Outputs
- Minimum number of plies n
- Cross‑section dimensions h × b (mm)
- Estimated mass G (g)
- Process Matching
- Small batches: Autoclave cure with UD prepreg
- Medium batches: UD prepreg + vacuum bag
- Large batches: UD prepreg + compression molding
4. Success Stories
4. Success Stories| Client | Beam Size | Load | Original Material Mass | UD‑CFRP Mass | Weight Savings | Performance Gain |
|---|---|---|---|---|---|---|
| Company A (Cobots) | 800 × 20 × 15 mm | 300 N | Aluminum 1.45 kg | 0.38 kg | 74 % | Fundamental frequency ↑ 120 % |
| Company B (AGV Chassis) | 2 m × 60 × 40 mm | 2 kN | Steel 12.3 kg | 2.7 kg | 78 % | Energy consumption ↓ 22 % |
| Company C (Optical Platform) | 1 m × 80 × 60 mm | 500 N | Aluminum honeycomb 4.2 kg | 1.1 kg | 74 % | Micro‑vibration ↓ 65 % |
5. B2B Delivery Capabilities
- Fabric Rolls: Width 1.27 m, length 100–300 m, 48 h dispatch
- Prepreg: Resin content 30–40 %, cold chain storage at 0–5 °C
- Secondary Processing: CNC milling, aluminum insert installation, laser marking, dynamic balancing
- Quality Assurance: Each batch includes a mechanical test report and Cpk data
6. Quick ROI Calculation
For a 2 m robotic arm beam:
- Material cost ↑ 35 %
- System weight ↓ 3.2 kg → Motor power requirement ↓ 18 %
- Annual energy savings ≈ 1 800 kWh → Payback period < 8 months
One‑Sentence Summary
Unidirectional Carbon Fiber Fabric enables beams to achieve “gram‑scale weight with ton‑scale stiffness” for the first time. Live stock, single‑roll minimum orders, and global delivery in 7 days.
